美安普礦山機(jī)械
MHP Series Hydraulic Cone Crusher
  • MHP Series Hydraulic Cone Crusher
0

MHP Series Hydraulic Cone Crusher

  • Device Details

  • Features

    Higher Production Capacity

    The technology of the MHP series cone crusher enables the higher production in the smallest space with smaller equipment. The combination of higher speed and stroke makes the MHP series' power and throughput greatly improved, making it the most productive crusher among competitors.


    Better Quality

    The MHP series cone crusher can be produced under a constant discharge port - avoiding the movement of the moving cone by the hydraulic cylinder, causing the change of the discharge opening during the production process, and maintaining the change of the discharge opening by rotating the concave adjustment method. The constant discharge opening increases the stability of the entire production process.


    Reduce Shutdown Time

    The MHP series cone crusher has a two-way iron-discharge hydraulic cylinder that allows the iron to pass through the crushing chamber, while many other manufacturers' crushers are shut down due to over-clamping. The hydraulic cleaning of the crushing chamber has a large stroke and is independent of the wear of the liner. It reduces the amount of work required to remove the clogging material in the crushing chamber and able to quickly clear the cavity, thereby reducing downtime and increasing operator confidence.


    Easier Maintenance

    The bronze bushings of the MHP series cone crusher can provide greater load capacity large vibration and dusty condition. Moreover, the bronze bushings are more affordable and can be replaced with ordinary tools. All parts of MHP series cone crusher can be disassembled and maintained from the top or side. The mantle and concave are easy to assemble and disassemble, no need to disassemble the shells and tighten the bolts. Therefore, the MHP series cone crusher is more convenient to replace the liner.


    Lower Maintenance Costs

    High-performance non-contact labyrinth seals are wear-free and increase the reliability of dust rodriers. The design is compact and makes fewer moving components in contact with rocks and dust. All parts of the crusher are wear-resistant – including replaceable mantle liner, mainframe base gasket, main frame pin sheath, drive bushing protection plate, counterweight guard plate, main frame liner and dead corner feed hopper - to minimize maintenance costs.


    Specification

    ModelInstalled Power(KW)CavityFeed Opening Setting(mm)Close Side Setting(mm)Capacity(tph)Weight(KG)
    MHP10090EF/F/M/C/EC20-1506-3245-1405400
    MHP200132EF/F/M/C25-18510-3890-25010400
    MHP300200EF/F/M/C/EC25-23310-45115-44015810
    MHP400315EF/F/M/C/EC30-29910-51140-63023000
    MHP500355EF/F/M/C/EC35-33510-51175-79033150
    MHP800600F/M/C/EC33-35310-51260-120064100
    MHP3220EF/F/M/C/EC18-2008-4594-38817600
    MHP4315EF/F/M/C/EC67-2378-45135-55525800
    MHP5370EF/F/M/C/EC50-3128-45158-60028820
    MHP6450EF/F/M/C/EC52-32810-45220-79045400




    Features

    Higher Production Capacity

    The technology of the MHP series cone crusher enables the higher production in the smallest space with smaller equipment. The combination of higher speed and stroke makes the MHP series' power and throughput greatly improved, making it the most productive crusher among competitors.


    Better Quality

    The MHP series cone crusher can be produced under a constant discharge port - avoiding the movement of the moving cone by the hydraulic cylinder, causing the change of the discharge opening during the production process, and maintaining the change of the discharge opening by rotating the concave adjustment method. The constant discharge opening increases the stability of the entire production process.


    Reduce Shutdown Time

    The MHP series cone crusher has a two-way iron-discharge hydraulic cylinder that allows the iron to pass through the crushing chamber, while many other manufacturers' crushers are shut down due to over-clamping. The hydraulic cleaning of the crushing chamber has a large stroke and is independent of the wear of the liner. It reduces the amount of work required to remove the clogging material in the crushing chamber and able to quickly clear the cavity, thereby reducing downtime and increasing operator confidence.


    Easier Maintenance

    The bronze bushings of the MHP series cone crusher can provide greater load capacity large vibration and dusty condition. Moreover, the bronze bushings are more affordable and can be replaced with ordinary tools. All parts of MHP series cone crusher can be disassembled and maintained from the top or side. The mantle and concave are easy to assemble and disassemble, no need to disassemble the shells and tighten the bolts. Therefore, the MHP series cone crusher is more convenient to replace the liner.


    Lower Maintenance Costs

    High-performance non-contact labyrinth seals are wear-free and increase the reliability of dust rodriers. The design is compact and makes fewer moving components in contact with rocks and dust. All parts of the crusher are wear-resistant – including replaceable mantle liner, mainframe base gasket, main frame pin sheath, drive bushing protection plate, counterweight guard plate, main frame liner and dead corner feed hopper - to minimize maintenance costs.


    Specification

    ModelInstalled Power(KW)CavityFeed Opening Setting(mm)Close Side Setting(mm)Capacity(tph)Weight(KG)
    MHP10090EF/F/M/C/EC20-1506-3245-1405400
    MHP200132EF/F/M/C25-18510-3890-25010400
    MHP300200EF/F/M/C/EC25-23310-45115-44015810
    MHP400315EF/F/M/C/EC30-29910-51140-63023000
    MHP500355EF/F/M/C/EC35-33510-51175-79033150
    MHP800600F/M/C/EC33-35310-51260-120064100
    MHP3220EF/F/M/C/EC18-2008-4594-38817600
    MHP4315EF/F/M/C/EC67-2378-45135-55525800
    MHP5370EF/F/M/C/EC50-3128-45158-60028820
    MHP6450EF/F/M/C/EC52-32810-45220-79045400
